ARH Combosmart
Arh Combosmart. Specifications below are read directly from the manufacturer's arh_combosmart datasheet. Each value carries the page of the document it came from.
Domestic price, shown in INR. Export pricing uses our separately maintained USD base.
Specifications
Arh Combosmart. Specifications below are read directly from the manufacturer's arh_combosmart datasheet. Each value carries the page of the document it came from.
Capture & sensor
Performance characteristics| Active Scan Area | 126 mm × 88 mm (4.96” × 3.46”) |
|---|---|
| Image Resolution | 500 PPI |
| Image Formats | BMP, JPG, JPG2000 and PNG |
| Image Color Depth | 24 bits/pixels [RGB, 8 bits/pixels (IR image)] |
| PC Connection | USB 2.0 high speed |
Hardware & interface
Connectivity & power| Illumination Sources | LED visible white, IR (B900), UVA (optional)* |
|---|---|
| Internal USB HUB | Integrated USB 2.0 HUB, 2 ports for external devices |
| Firmware Upgrade | Automatic, via USB |
| Power supply | Universal external power supply, 100-240 V AC, 50/60 Hz |
Environmental
Operating limits| Adaptive Light Control | YES |
|---|---|
| IP rate / Case | IP53 / sturdy ABS.PC plastic & metal |
Physical
Size & weight| Programming Languages | C/C++, C#, Visual Basic 6.0, Delphi, VB.NET, Java |
|---|---|
| Window glass | 4 mm (0.16”) tempered glass |
Data & formats
Interchange standards| Magnetic Stripe Option**** | Track 1, 2 and 3 stripes according to related ISO, ANSI and AAMVA standards |
|---|---|
| Contact Smart Card Option*** | ISO 7816 Class A, AB and C, ISO 7816 & EMV2 2000 Level 1 |
| Compliances | FCC, CE, WEEE, RoHS |
Software
Compatibility & drivers| VIZ Reading | Available with ARH VIZ OCR software |
|---|---|
| Software Development Kit (SDK) | Complete SDK including DLLs and demo programs |
Other
Additional detail| Automatic Document Detection (ADD) | YES |
|---|---|
| Reflection Removal (RR) | YES |
| Advanced Document Authentication | Data consistency checks: MRZ, Bar codes, RFID** |
| Internal Memory | Storing factory calibration |
| Security | Kensington security slot |
| Maintenance | No moving parts, maintenance-free operation |
| Warranty | 3-year warranty, upgradeable |
Certifications & standards
Standards and approvals named in this product's published specification.
Export & compliance
What is confirmed at the point of order, and what the proforma settles in writing.
Software packages are released per model and platform by the manufacturer and are not shipped with the unit. Tell the export desk which platform and firmware you need and we will send the matching package.
